MCF548x Reference Manual, Rev. 3

22-106

Freescale Semiconductor

Table 22-111

lists several different descriptor header values that can be used for the outbound TLS

descriptor 1 shown in

Table 22-110

.

At the conclusion of inbound TLS descriptor 2, the crypto-channel has calculated the HMAC, placed it in

memory, and has reset and released the MDEU. The host can compare the HMAC generated by inbound

descriptor 2 with the HMAC that was transmitted as part of the record. If the HMACs match, the record is

known to have arrived unmodified, and can be passed to the application layer.

PTR_1

Pointer (not used)

NULL

LEN_2

IV Length

NULL

PTR_2

IV Pointer

NULL

LEN_3

Key Length

Number of bytes of HMAC key

PTR_3

Key Pointer

Pointer to HMAC key

LEN_4

Data In Length

Number of bytes of data to be hashed

PTR_4

Data In Pointer

Pointer to data to perform hash upon

LEN_5

Data Out Length

NULL

PTR_5

Data Out Pointer

NULL

LEN_6

IV Out Length

Number of bytes of data after hashing (16, 20, or 32)

PTR_6

IV Out Pointer

Pointer to location where hash output is to be written

LEN_7

MAC Out Length

NULL

PTR_7

MAC Out Pointer

NULL

PTR_NEXT

Next Descriptor Pointer Null or pointer to unrelated next descriptor

Table 22-111. Typical Header Values for Outbound TLS Descriptor One Format

Header Value

Algorithm

HMAC

Pad

0x31D00010

SHA256

Yes

Yes

0x31E00010

MD5

Yes

Yes

0x31C00010

SHA

Yes

Yes

Table 22-110. Inbound TLS Descriptor Two Format (Continued)

Field Name

Value/Type

Description
