29.2.2.2
USB Control Register (USBCR)
The USBCR configures features of the module.
6–4
—
Reserved, should be cleared.
3–0
ISOERREP Isochronous error endpoint. This is the endpoint number for the isochronous OUT endpoint
that has experienced a PID sequencing error and caused the ISO_ERR interrupt to assert.
The value in this register will always reflect the endpoint number for the last isochronous
OUT endpoint to experience a PID sequencing error (or 0x0 if no PID sequencing errors
have occurred). It is not cleared along with the USBISR[ISOERR] interrupt bit.
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
R
Uninitialized
W
Reset
Uninitialized
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
R
Uninitialized
RAM
SPLIT
—
RAM
EN
0
APP
LOCK
0
W
RST
RESUME
Reset
Uninitialized
0
0
0
0
0
0
0
0
Reg
Addr
MBAR + 0xB404
Figure 29-3. USB Control Register (USBCR)
Table 29-2. USBSR Field Descriptions
Bits
Name
Description
