17 Parameter reference
17.2 Parameter list | C01670
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01670
C01671
Parameter | Name:
C01670 | L_ComparePhi 1-5: Function
Data type: UNSIGNED_8
Index: 22905
d
= 5979
h
Selection of comparison operation
• If the statement of the selected comparison operation is true, the binary bOut output will be set to TRUE.
Selection list
1 In1 = In2
2 In1 > In2
3 In1 < In2
4 |In1| = |In2|
5 |In1| > |In2|
6 |In1| < |In2|
Subcodes Lenze setting Info
C01670/1 1: In1 = In2 L_ComparePhi_1 : Function
C01670/2 1: In1 = In2 L_ComparePhi_2 : Function
C01670/3 1: In1 = In2 L_ComparePhi_3 : Function
C01670/4 1: In1 = In2 L_ComparePhi_4 : Function
C01670/5 1: In1 = In2 L_ComparePhi_5 : Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01671 | L_ComparePhi 1-5: Hysteresis
Data type: INTEGER_32
Index: 22904
d
= 5978
h
Hysteresis for the comparison function
Setting range
(min. value | unit | max. value)
0 Incr. 1073741824
Subcodes Lenze setting Info
C01671/1 0 incr. L_ComparePhi_1 : Hysteresis
C01671/2 0 incr. L_ComparePhi_2 : Hysteresis
C01671/3 0 incr. L_ComparePhi_3 : Hysteresis
C01671/4 0 incr. L_ComparePhi_4 : Hysteresis
C01671/5 0 incr. L_ComparePhi_5 : Hysteresis
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
