Lenze 8400 TopLine - Manual (Page 1041)

Lenze · 8400 TopLine · Reference manual · DMS 6.0 EN · 06/2014 · TD05/TD14
1041
17 Parameter reference
17.2 Parameter list | C00650
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00650
C00653
Parameter | Name:
C00650 | L_Arithmetik 3-5: Function
Data type: UNSIGNED_8
Index: 23925
d
= 5D75
h
Selection of the internal arithmetics
Selection list
0 nOut_a = nIn1_a
1 nOut_a = nIn1_a + nIn2_a
2 nOut_a = nIn1_a - nIn2_a
3 nOut_a = (nIn1_a * nIn2_a) / 100%
4 nOut_a = (nIn1_a * 1%) / |nIn2_a|
5 nOut_a = (nIn1_a * 100%) / (100% -
nIn2_a)
Subcodes Lenze setting Info
C00650/1 0: nOut_a = nIn1_a L_Arithmetik_3 : Function
C00650/2 0: nOut_a = nIn1_a L_Arithmetik_4 : Function
C00650/3 0: nOut_a = nIn1_a L_Arithmetik_5 : Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00653 | Sensibility - Setpoint feedforward control
Data type: UNSIGNED_8
Index: 23922
d
= 5D72
h
From version 12.00.00
Selection of the sensitivity of the differential setpoint feedforward control
• Depending on the selection, the number of indicated higher-order bits is evaluated.
Note:
The most significant bit determines the sign of the value, the remaining bits determine the numerical value.
Selection list
Info
0 Inactive
1 15 bits
Bit 0 ... bit 14 are evaluated
2 14 bits Bit 0 ... bit 13 are evaluated
3 13 bits Bit 0 ... bit 12 are evaluated
4 12 bits Bit 0 ... bit 11 are evaluated
5 11 Bit Bit 0 ... bit 10 are evaluated
6 10 Bit Bit 0 ... bit 9 are evaluated
7 9 Bit Bit 0 ... bit 8 are evaluated
Subcodes Lenze setting Info
C00653/1 0: Inactive Sensibility - Setpoint feedforward control
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
