938 Chapter 10 Using Filters
Parameters in the Inspector
Angle: Sets the angle at which the object is extruded.
Distance: Sets the distance the object is extruded. Values range from 0 to 100.
Clipping: Sets the distance at which the extrusion is clipped. Values range from –100
to 100.
Back Size: Sets the size of the back object, as a proportion of its original size. Values
range from 0 to 2.
Face Brightness: Sets a brightness level applied to the face of the object. Values range
from 0 to 2.
Front Brightness: Sets a brightness level applied to the front of the object. Values
range from 0 to 2.
Back Brightness: Sets a brightness level applied to the back of the object. Values range
from 0 to 2.
Extrude Style: Selects the method used to extrude the sides of the object. Shading or
Gradient can be selected. With Shading selected, the color values of the pixels at the
edges of the object are used along the extrusion. With Gradient selected, a gradient
preset or custom gradient can be used.
Gradient: Selects a gradient preset to be applied to the object. Can also be used to
edit a custom gradient. The gradient is applied only if the Extrude Style is set to
Gradient.
Mix: Sets the amount of the filtered frame to be mixed with the original source frame.
Values range from 0 to 100%.
HUD Controls
The HUD contains all of the same controls as the Inspector, with the exception of the
Gradient control.
Halftone
This filter reduces an image to a black and white version of itself, simulating the
halftone screening method for print, in which the shadows and highlights of an image
are recreated using patterns of small and large dots.
