3 Working with the FB editor
3.6 Comparing interconnections
96
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.6.2 Contents and representation of the comparison
The following elements of an FB interconnection are considered in a comparison. The features of the
elements to be compared are listed as well:
Every object available in an FB interconnection is checked for existence in the other interconnection.
If the object concerned is available but with another declaration or version, the deviating features
are displayed by values in the report.
Example: The freely instanced module A is available in the project and the device but has been taken
from a different library version in the device. Both version numbers are presented next to each other
in the report in order to recognise the deviation.
Element Properties
Task Name
Cycle time
Type
Function blocks to be instanced freely Processing sequence
Library version
Instance name
Type
System blocks Name
Version
Port blocks Name
Data types of the element variables
Variable declarations (local & global) Variable name
Data type
Variable assignments Number
User parameter declarations Name
Code number
Data type
Setting range (lower limit, upper limit)
Unit
Variable instance name
Variable setting range (lower limit, upper limit)
Write/read permissions
Dependencies on the controller inhibit and Plc-stop
User parameter assignments Number
Code number
Signal flows (connection lines) Signal sources and target
