5 Function blocks
5.79 L_DevWriteParDInt - writing to parameters of the DINT type
288
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
Parameters
Identifier/data type Value/meaning
dnState
DINT
Status (bit coded)
• Bits that are not listed have not been assigned with a status (always "0").
Bit 0 Write request has been sent to the operating system and the FB is
waiting for a response from the device addressed (signal bBusy).
Bit 1 Write request has been executed correctly (signal bDone).
Bit 15 Error (group signal for bit 16 ...31).
Bit 16 Configuration error: Invalid code.
Bit 17 Configuration error: Invalid subcode.
Bit 19 Configuration error: Invalid target address.
Bit 20 Time-out error: The addressed device did not respond within the
time-out time, the write request has been deleted.
Bit 21 Error: Invalid data type.
• Use the table of attributes to check the data type of the parame-
ter you want to write. If it is not a DINT data type, use the
FB L_DevParWriteFix instead for writing the parameter.
Bit 22 Error: Limit value has been exceeded.
Bit 24 Error: Access is not permitted.
Bit 25 Error: No element of selection list.
Bit 26 Error: Parameter writing is not permitted.
Bit 27 Error: Parameter writing is only permitted when the controller is in-
hibited.
Bit 28 Error: Parameter writing is only permitted when the application has
stopped.
bBusy
BOOL
Status output "Write request transmitted"
TRUE The write request has been sent to the operating system and the FB
is waiting for a response from the device addressed.
TRUEFALSE The write request has been completed.
bDone
BOOL
Status output "Write request executed correctly"
• The output remains set until bExecute is reset to FALSE (however, at least for one
task cycle).
TRUE The write request has been executed correctly.
bError
BOOL
Status output "Error"
TRUE An error has occurred during processing.
• For details, please see the status output dnState.
Parameter Possible settings Info
C05920 0 12000 Code
• Initialisation: 2
C05921 0 255 Subcode
• Initialisation: 0
C05922 Interface
• Currently only the Lenze setting
"Own device" is supported.
1 Own device
2 CAN on-board
3 Module in MXI1
4 Module in MXI2
