5 Function blocks
5.40 L_DcGetBitOfDWord - bit operation
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.40 L_DcGetBitOfDWord - bit operation
This FB returns the state of a single bit within a "DWORD" value.
Inputs
Outputs
Function library: LenzeDataConversion
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
dwInput
DWORD
Input signal
byBitNr
BYTE
No. (0 ... 31) of the bit of dwInput the state of which is to be detected.
Identifier/data type Value/meaning
bBit
BOOL
State of bit byBitNr of dwInput.
/B'F*HW%LW2I':RUG
GZ,QSXW
E\%LW1U
E%LW
