5 Function blocks
5.185 L_TbNegInt - negation (for "INT" data type)
604
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.185 L_TbNegInt - negation (for "INT" data type)
This function block inverts the sign of the input signal, i.e. the input signal is multiplied by -1 and is
then output.
• The value output to output nOut is internally limited to ±2 15 -1.
• The FB L_TbNegSelInt is available for optional inversion.
Inputs
Outputs
Function library: LenzeToolbox FB is available as of library V02.05.xx.xx!
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
nIn
INT
Input signal
Identifier/data type Value/meaning
nOut
INT
Output signal
Q2XW Q,Q
/B7E1HJ,QW
