Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
511
5 Function blocks
5.136 L_SdSetAxisData - machine parameters
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Parameter

Note!
Observe that the index of the codes listed in the following only applies to the first in-
stance!
Parameter Possible settings Information
C04240 1 2147483647 Gearbox factor numerator
• Initialisation: 1
C04241 1 2147483647 Gearbox factor denominator
• Initialisation: 1
C04242 0.0001 unit/inc 214748.3647 Feed constant
• Initialisation: 360 unit/inc
C04243 Path unit
0 User-defined Selection in C04244
1 inc
2 μM
3 mm
4 M
5 inch
6 yard
7 °
Lenze setting
C04244 String of digits with max. 8 characters User-defined path unit
C04245 Time unit
• The time base unit is default set to
"s" and cannot be changed!
0 User-defined
1 ms
2 s
3 min
4 H
C04246
As of library V02.07.xx.xx
String of digits with max. 16 characters Axis name
• Read only
C04248 0.0000 Unit 214748.3647 Cycle
• Initialisation: 360 unit
C04249 10 Bit 24 Resolution of an encoder revolution
• Initialisation: 16 bits
C04251 -214748.3647 Unit/t 214748.3647 Reference speed
• Initialisation:
214748.3647 unit/t
C04252
As of library V02.00.xx.xx
Traversing range
0 Unlimited
1 Limited
2 Modulo
Lenze setting
C04258 -2147483.647 2147483.647 Resulting gearbox factor
• Read only
C04259 -214748.3647 Incr./unit 214748.3647 Resolution of a unit
• Read only
