2 Introduction
2.3 Parameterisable function blocks
18
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
2.3 Parameterisable function blocks
Some function blocks have parameters which serve to change particular settings during operation,
if required, or which display actual values & status information.
Parameters, codes & subcodes
All parameters are stored in "codes".
• The codes are numbered and indicated in the documentation with a preceding "C", e.g.
"C00002".
• For the sake of clarity some codes contain "subcodes" in which parameters are stored. In the do-
cumentation, code and subcode are divided by a "/", e.g. "C00118/3".
Code ranges
The codes for the 9400 Servo Drives are divided into the following ranges:
Assignment Range Contents
Firmware C00000 ... C02999 Codes of the standard device
TA C03000 ... C03099 Basic codes of the technology application
C03100 ... C03499 Multiplexer codes of the technology application
C03500 ... C03999 Codes of used function blocks
Libraries C04000 ... C04199 LenzeToolbox
C04200 ... C04399 LenzeServoDrive
C04400 ... C04499 LenzeDataConversion
C04500 ... C04799 LenzePositioning
C04800 ... C04999 LenzeWinder
C05000 ... C05299 LenzeLineDrive
C05300 ... C05599 LenzeCam
C05600 ... C05899 - Reserve -
C05900 ... C05999 LenzeDevice9400
User C06000 ... C08999 Free range for user codes
C09000 ... C12999 - Reserve -
Modules C13000 ... C13999 Extension/communication module in the MXI1 module receptacle
C14000 ... C14999 Extension/communication module in the MXI2 module receptacle
C15000 ... C15999 Safety module in the MSI module receptacle for safety engineering
C16000 ... - Reserve -
