3 Working with the FB editor
3.4 Creating/reconfiguring the interconnection
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.4 Creating/reconfiguring the interconnection
How to proceed:
1. Enable FB Editor.
• Only required if a Lenze technology application is to be reconfigured.
• If no application or the "empty application" from the catalogue has been selected, the FB Edi-
tor is already enabled.
2. Insert required objects into the interconnection.
3. Hide unneeded inputs/outputs of function blocks and system blocks to obtain a clearly arran-
ged interconnection.
4. Arrange the objects in the drawing area in a reasonable manner.
5. Establish the connections required for the desired function.
6. If required, change (optimise) the processing order of the function blocks.
7. Compile the completed interconnection.

Tip!
Detailed information on the individual steps can be obtained from the following subchap-
ters!
3.4.1 Enabling the FB Editor
If you have selected a technology application from the catalogue for the controller, the FB Editor is
first in the "Viewer" mode. The interconnection of the technology application is displayed but can-
not be modified.
To be able to reconfigure the defined interconnection and to add further functions, the FB Editor
must be enabled explicitly.

How to enable the FB Editor:
1. When being in offline mode, press the Enable Editor button.
2. Confirm the query whether the FB Editor is to be enabled with OK.

Note!
When the FB Editor is enabled, the parameter dialogs for the technology application are
replaced by general dialogs. The dialogs for the parameterisation of the system and
function blocks contained in the interconnection can still be used.
Furthermore, all multiplexers are removed from the interconnection and the currently
parameterised signal combinations are replaced by connections.
