5 Function blocks
5.120 L_SdGetAxisData - Reading out machine parameters from axis data
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Parameter
dwBitsPerRevolution
DWORD
Resolution of an encoder revolution
• Display parameter: C04418
10 Bit / encoder revolution
... ...
24 Bit / encoder revolution
dwIncrPerRevolution
DWORD
Resolution of a revolution in [increments]
dwFeedType
DWORD
Traversing range
• Display parameter: C04422
0 Unlimited
1 Limited
2 Modulo

Note!
Observe that the index of the codes listed in the following only applies to the first in-
stance!
Parameter Possible settings Information
C04410/1 1 2147483647 Gearbox factor (numerator)
• Read only
C04410/2 1 2147483647 Gearbox factor (denominator)
• Read only
C04411 0.0001 Unit/incr. 214748.3647 Feed constant
• Read only
C04412 String of digits with max. 16 characters Unit
• Read only
C04413 String of digits with max. 8 characters Time unit
• Read only
C04414 String of digits with max. 16 characters Axis name
• Read only
C04416 0.0000 Unit 214748.3647 Cycle
• Read only
C04418 10 Bit 24 Resolution of an encoder revolution
• Read only
C04420 -214748.3647 Unit/t 214748.3647 Reference speed
• Read only
C04422 Traversing range
• Read only
0 Unlimited
1 Limited
2 Modulo
C04424 -2147483.647 2147483.647 Resulting gearbox factor
• Read only
C04425 -214748.3647 Incr./unit 214748.3647 Resolution of a unit
• Read only
Identifier/data type Value/meaning
