4 Short overview
4.2 Digital signal processing
102
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.2 Digital signal processing
Logic operations for "BOOL" data type
Bit operations for "INT" data type
Bit operations for "DINT" data type
Function block Function From library
L_TbCount Upcounter and downcounter with adjustable limita-
tion
LenzeToolbox V01.00.xx.xx
L_TbDelay Binary delay element LenzeToolbox V01.00.xx.xx
L_TbFlipFlopD D flipflop
• Can be used for evaluation and storage of digital
signal edges.
LenzeToolbox V01.00.xx.xx
L_TbFlipFlopRS RS flipflop
• Can be used for evaluation and storage of digital
signals.
LenzeToolbox V01.00.xx.xx
L_TbOscillator Rectangular pulse generator with parameterisable
pulse/dead time
LenzeToolbox V01.00.xx.xx
L_TbTransition Signal edge evaluation
• Can be used to generate timed and retriggerable
pulses.
LenzeToolbox V01.00.xx.xx
Function block Logic operation From library
L_TbAnd AND (2 inputs) LenzeToolbox V01.00.xx.xx
L_Tb5And AND (5 inputs) LenzeToolbox V01.00.xx.xx
L_TbOr OR (2 inputs) LenzeToolbox V01.00.xx.xx
L_Tb5Or OR (5 inputs) LenzeToolbox V01.00.xx.xx
L_TbNand NOT-AND (2 inputs) LenzeToolbox V01.00.xx.xx
L_Tb5Nand NOT-AND (5 inputs) LenzeToolbox V01.00.xx.xx
L_TbNor NOT-OR (2 inputs) LenzeToolbox V01.00.xx.xx
L_Tb5Nor NOT-OR (5 inputs) LenzeToolbox V01.00.xx.xx
L_TbXor EXCLUSIVE-OR (2 inputs) LenzeToolbox V01.00.xx.xx
L_Tb5Xor EXCLUSIVE-OR (5 inputs) LenzeToolbox V01.00.xx.xx
L_TbNot Negation (inverter) LenzeToolbox V01.00.xx.xx
Function block Function From library
L_DcBitShiftInt Bit shift operation LenzeDataConversion
V02.02.xx.xx
Function block Function From library
L_DcBitShift Bit shift operation LenzeDataConversion
V01.00.xx.xx
