6 Table of attributes
660
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C05297 Position output 19278 4B4E S 1 INTEGER_32 10000 
C05298 Speed output 19277 4B4D S 1 INTEGER_32 10000 
C05299 Status 19276 4B4C S 1 INTEGER_32 1 
L_LdClutchAxisP
C05070 Ramps for coupling 19505 4C31 A 3 INTEGER_32 1000  
C05071 Unit 19504 4C30 A 2 VISIBLE_STRING 1 
C05072 Reference speed 19503 4C2F S 1 INTEGER_32 10000 
C05074 Status 19501 4C2D S 1 INTEGER_32 1 
C05076 Set position after declutching 19499 4C2B S 1 INTEGER_32 10000 
C05077 Actual position of the master angle 19498 4C2A S 1 INTEGER_32 10000 
C05078 Master position at the input 19497 4C29 S 1 INTEGER_32 10000 
C05079 Master position at the output 19496 4C28 S 1 INTEGER_32 10000 
L_LdClutchV
C05080 Ramps for coupling 19495 4C27 A 3 UNSIGNED_32 1000  
C05081 Speed unit 19494 4C26 S 1 VISIBLE_STRING 1 
C05082 Reference speed 19493 4C25 S 1 INTEGER_32 10000 
C05083 S-ramp time 19492 4C24 S 1 UNSIGNED_32 1000  
C05085 Status 19490 4C22 S 1 INTEGER_32 1 
C05087 Setpoint speed after declutching 19488 4C20 S 1 INTEGER_32 10000 
C05088 Speed at the input 19487 4C1F S 1 INTEGER_32 10000 
C05089 Speed at the output 19486 4C1E S 1 INTEGER_32 10000 
L_LdConvAxisV
C05160 Coupling measuring systems X and Y 19415 4BD7 S 1 UNSIGNED_32 1   
C05161 Cycles 19414 4BD6 A 2 INTEGER_32 10000 
C05162 Coupling factors 19413 4BD5 A 2 INTEGER_32 10000   
C05163 User-defined unit 19412 4BD4 A 2 VISIBLE_STRING 1 
C05165 Speeds 19410 4BD2 A 2 INTEGER_32 10000 
C05169 Status 19406 4BCE S 1 INTEGER_32 1 
L_LdExtrapolate
C05000 Number of extrapolation cycles 19575 4C77 S 1 UNSIGNED_16 1  
C05001 Unit 19574 4C76 A 2 VISIBLE_STRING 1 
C05007 Speed at the output 19568 4C70 S 1 INTEGER_32 10000 
C05008 Position at the output 19567 4C6F S 1 INTEGER_32 10000 
C05009 Extrapolation cycl. > selection 19566 4C6E S 1 UNSIGNED_8 1 
L_LdLinearCoupling
C05181 Status 19394 4BC2 S 1 INTEGER_32 1 
C05182 Unit 19393 4BC1 A 4 VISIBLE_STRING 1 
C05183 Speed X at the output 19392 4BC0 S 1 INTEGER_32 10000 
C05184 Speed Y at the output 19391 4BBF S 1 INTEGER_32 10000 
C05186 Position X at the input 19389 4BBD S 1 INTEGER_32 10000 
C05187 Trimming X 19388 4BBC S 1 INTEGER_32 10000 
C05188 Position X at the output 19387 4BBB S 1 INTEGER_32 10000 
C05189 Position Y at the output 19386 4BBA S 1 INTEGER_32 10000 
L_LdMonitFollowError
C05175 Following error at the input 19400 4BC8 S 1 INTEGER_32 10000 
C05176 Position unit 19399 4BC7 S 1 VISIBLE_STRING 1 
C05178 Following error outside the tolerance 19397 4BC5 S 1 UNSIGNED_8 1 
C05179 Following error monitoring is active. 19396 4BC4 S 1 UNSIGNED_8 1 
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
