5 Function blocks
5.114 L_PosSequencer - sequence control
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
bEnableFollower
BOOL
Enable signal for setpoint follower
• This output is intended for the enable of a setpoint follower during a stand-by
program step.
• Connect this output, if required, with the input bEnable of the corresponding set-
point follower (SB LS_SpeedFollower, SB LS_TorqueFollower or
SB LS_PositionFollower).
• Display parameter: C04690/10
FALSE No enable since the basic function "Positioning" is active.
TRUE Enable is possible since stand-by program step is active.
dwDigitalOutputs
DWORD
Sequencer outputs 1 ... 32 (bit coded)
• The sequencer outputs can be set to "0" or "1" by means of the "Switching" action
type during the runtime of the positioning program.
• For the transmission of individual control signals a DWORD-to-BOOL converter
can be connected to this input.
• Display parameter: C04693/2
bits0 Sequencer output 1
bits1 Sequencer output 2
... ...
bits31 Sequencer output 32
Identifier/data type Value/meaning
