5 Function blocks
5.23 L_DcByteBitand - bit combination
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.23 L_DcByteBitand - bit combination
This FB carries out a bit-by-bit AND operation of two input values of "BYTE" type and also outputs
the results as "BYTE".
Inputs
Outputs
Function
Example
Function library: LenzeDataConversion FB is available as of library V02.02!
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
byIn1
BYTE
Value 1 for bit-by-bit AND combination
byIn2
BYTE
Value 2 for bit-by-bit AND combination
Identifier/data type Value/meaning
byOut
BYTE
Result of the bit-by-bit AND operation of byIn1 and byIn2
byIn1 - bit n byIn2 - bit n byOut - bit n
0 0 0
0 1 0
1 0 0
1 1 1
byIn1 = 00101001
byIn2 = 01111000
--------
byOut = 00101000
/B'F%\WH%LWDQG
E\,Q
E\,Q
E\2XW
%LW %LW
