3 Working with the FB editor
3.4 Creating/reconfiguring the interconnection
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6. Press Insert button.
• The system block selected is inserted in the interconnection.
Context menu for the system block
If you right-click on the header of a system block, a context menu opens via which you can execute
the following functions in addition to the general processing functions (Copy, Insert, Delete):
Related topics:
 Deleting objects that are no longer required ( 70)
 Changing connector visibilities ( 72)
 Arranging objects in the drawing area ( 73)
 Creating/deleting connections ( 74)
Command Function
Connector visibilities... Define visible inputs and outputs for system blocks.
 Changing connector visibilities ( 72)
Parameter... Open parameter list or parameterisation dialog of the system block.
Help Show online help for the system block.
"
