5 Function blocks
5.11 L_CamSyncIn - synchronous/oversynchronous clutch-in
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
Parameter
dnSyncPos_p
DINT
Synchronous position in [increments]
• Starting position of the synchronous range.
• C05606/3 indicates the synchronous position in the real unit of the machine.
bReset
BOOL
Reset function
TRUE Function is reset to evaluate a new touch probe or the "Manual
clutch-in" via bManualSync request.
bManualSync
BOOL
Manual clutch-in
• Example: Manually controlled top cut with flying saw.
TRUE Start clutch-in process immediately.
Note: At the same time, a speed must be applied at the dnSpeedIn_s
input for the clutch-in ramp to be calculated. Otherwise, the clutch-
in process will not be started in the FB.
AxisData Machine parameters
• For accepting the machine parameters of the drive/motor, connect this input
with the output DI_AxisData of the SB LS_DriveInterface.
Identifier/data type Value/meaning
dnPosOut_p
DINT
Output position in [increments]
• C05607 indicates the output position in the real unit of the machine.
dnSpeedOut_s
DINT
Output speed given as speed in [rpm]
• C05608 indicates the output speed in the real unit of the machine.
bSync
BOOL
"Clutched-in" status
TRUE Input and output run synchronously.
bAcc
BOOL
"Acceleration phase active" status
TRUE Acceleration phase is active.
bError
BOOL
"Error" status
TRUE An error has occurred (group signal).
• For details see display parameter C05609.
Parameter Possible settings Information
C05600/1 String of digits Position unit
• Read only
C05600/2 String of digits Speed unit
• Read only
C05601 0.0000 Unit/t 214748.3647 Reference speed
• Read only
C05602 0.0000 Unit/t 214748.3647 Maximum speed
• For oversynchronous clutch-in.
• Initialisation: 0.0000 unit/t
C05603 0.001 s 100.000 Minimum clutch-in time
• Time for the clutch-in process
which must not be undershot.
• Initialisation: 1.000 s
C05605 -214748.3647 Unit/t 214748.3647 Input speed
• Display of the dnSpeedIn_s input
signal in the real unit of the ma-
chine.
Identifier/data type Information/possible settings
