5.84 L_LdClutchAxisP - virtual clutch for synchronism
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Parameters
Parameter Possible settings Info
C05070/1 0.010 s 130.000 Ramp: Clutch in
• Acceleration ramp for synchronis-
ing to the master shaft.
• This specification and the refe-
rence speed that exists in the axis
data serve to calculate an internal
acceleration. This acceleration
serves to calculate the clutch-in
path.
• When a higher clutch-in time is
set, the clutch-in path can also be
executed via several cycles.
• Initialisation: 1.000 s
C05070/2 0.010 s 130.000 Ramp: Declutch
• Deceleration ramp for shutdown
of the master position.
• This specification and the refe-
rence speed that exists in the axis
data serve to calculate an internal
acceleration. This acceleration
serves to calculate the declutch
path.
• When a higher declutch time is
set, the declutch path can also be
executed via several cycles.
• Initialisation: 1.000 s
C05070/3 0.010 s 130.000 Ramp: Positive opening operation
• Deceleration ramp for the positive
opening operation.
• Initialisation: 1.000 s
C05071/1
From library V02.02.xx.xx onwards
Character string Position unit
• Read only
C05071/2
From library V02.02.xx.xx onwards
Character string Speed unit
• Read only
C05072
From library V02.02.xx.xx onwards
-214748.3647 Unit/t 214748.3647 Reference speed
• Read only
• For input orientation for speed
entries.
C05074 -2147483647 2147483647 Status
• Display of the bit-coded output si-
gnal dnState.
C05076 -214748.3647 Unit 214748.3647 Set position after declutching
• Display of the dnOpenPosition_p
input signal in the real unit of the
machine.
C05077 -214748.3647 Unit 214748.3647 Actual position of the master angle
• Display of the dnActPostion_p in-
put signal in the real unit of the
machine.
C05078 -214748.3647 Unit 214748.3647 Master position at the input
• Display of the dnSetPostion_p in-
put signal in the real unit of the
machine.
C05079 -214748.3647 Unit 214748.3647 Master position at the output
• Display of the dnPosOut_p output
signal in the real unit of the ma-
chine.
