5 Function blocks
5.79 L_DevWriteParDInt - writing to parameters of the DINT type
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.79 L_DevWriteParDInt - writing to parameters of the DINT type
This FB writes a parameter of data type "DINT" with the value assigned to the input dnData.
• Only internal parameters (codes) of the controller can be written.
• In contrast to the
L_DevParWriteFix FB, the parameter of this FB to be written is addressed via
parameters and not via FB inputs.
• The FB supports both one-time and cyclic writing in a parameterisable time interval.
• To write a different data type as "DINT" to a parameter, the FB
L_DevParWriteFix is to be used
instead. ( 271)
Inputs
Function library: LenzeDevice9400 FB is available from library V02.00.xx.xx onwards!
FB may only be used for firmware from V1.50 onwards!
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel

Note!
The following applies to the 9400 ServoPLC: The FB may not be called with the same in-
stance in several tasks.
Identifier/data type Information/possible settings
bExecute
BOOL
Activate a write request.
FALSETRUE If cycle time (C05925) = "0 s":
Write the parameter addressed via C05920 ...C05923 once with the
value assigned to the dnData input.
If cycle time (C05925) > "0 s":
Write the parameter addressed via C05920 ...C05923 cyclically with
the value assigned to the dnData input.
TRUEFALSE Deactivate cyclic writing again.
/B'HY:ULWH3DU',QW
GQ6WDWH
E%XV\
E'RQH
E(UURU
E([HFXWH
GQ'DWD
&
&RGH 6XEFRGH
,QWHUIDFH
7DUJHWDGUHVV
&\FOHWLPH
& &
&
&
&
7LPHRXWWLPH &
