5 Function blocks
5.114 L_PosSequencer - sequence control
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.114.3.10 Action type "Stand-by"
5 actions of type "Stand-by" are available for the temporary activation of a setpoint follower.
• For this purpose the output bEnableFollower must be connected to the enable input bEnable of
the corresponding setpoint follower (SB LS_SpeedFollower, SB LS_TorqueFollower or
SB LS_PositionFollower).
• The enable signal at the output bEnableFollower is applied until the condition for exiting the
stand-by is met.
Action call (entry in the sequence table)
with action number xxx = 001 ... 005
Parameter
The available actions 1 ... 5 are indicated via the subcodes 1 ... 5.
Parameter Possible settings Information
C04600/1...5 Text Comment on "Stand-by" step
• Option for description of the func-
tion for keypad/HMI.
C04601/1...5 Input for "Stand-by" end
1 Sequencer input 1
(Bit 0 of dwDigitalInputs)
2 Sequencer input 2
(Bit 1 of dwDigitalInputs)
... ...
32 Sequencer input 32
(Bit 31 of dwDigitalInputs)
C04602/1...5 Signal state for "Stand-by" end
• Only when the input for the end
of "Stand-by" has reached this sta-
te, this stand-by step is exited and
the sequence step is processed.
0 Sequence step when bit state is "0"
1 Sequence step when bit state is "1"
Standby
1 0 x x x
