5 Function blocks
5.94 L_LdPosCtrlLin - Master value adjustment via position
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
The FB LdPosCtrlLin serves to constantly adjust the x offset position. For this purpose the FB must be
interconnected as follows in connection with the L_LdLinearCoupling synchronous function:
[5-53] Model connection
