6 Table of attributes
656
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6 Table of attributes
The table of attributes contains information required for a communication to the controller via pa-
rameters.
How to read the table of attributes:
Table of attributes
Column Meaning Entry
Code Parameter name Cxxxxx
Name Parameter short text (display text) Text
Index dec Index under which the parameter will be
addressed.
The subindex for array variables corresponds to the
Lenze subcode number.
24575 - Lenze code number Only required if accessed via a bus sys-
tem.
hex 5FFF
h
- Lenze code number
Data DS Data structure S Single variable
(only one parameter element)
A Array variable
(several parameter elements)
DA Number of array elements (subcodes) Number
DT Data type BITFIELD_8 1 byte bit coded
BITFIELD_16 2 bytes bit coded
BITFIELD_32 4 bytes bit coded
INTEGER_8 1 byte with sign
INTEGER_16 2 bytes with sign
INTEGER_32 4 bytes with sign
UNSIGNED_8 1 byte without sign
UNSIGNED_16 2 bytes without sign
UNSIGNED_32 4 bytes without sign
VISIBLE_STRING ASCII string
Factor Factor for data transmission via a bus system, de-
pending on the number of decimal positions
Factor 1 ≡ no decimal positions
10 ≡ 1 decimal position
100 ≡ 2 decimal positions
1000 ≡ 3 decimal positions
10000 ≡ 4 decimal positions
Access R Read access  Reading permitted
W Write access  Writing permitted
CINH Controller inhibit required  Writing is only possible if the controller is inhibited
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
L_CamClutchPos
C05480 Position unit 19095 4A97 A 2 VISIBLE_STRING 1 
C05481 Declutch distance 19094 4A96 A 2 INTEGER_32 10000  
C05482 Ramp: Positive opening operation 19093 4A95 S 1 INTEGER_32 1000  
C05486 Input position 19089 4A91 A 2 INTEGER_32 10000 
C05487 Output position 19088 4A90 S 1 INTEGER_32 10000 
C05488 Output speed 19087 4A8F S 1 INTEGER_32 10000 
C05489 Status 19086 4A8E S 1 INTEGER_32 1 
L_CamContactor
C05520 Position unit 19055 4A6F A 2 VISIBLE_STRING 1 
C05521 Dynamisation - switch-on position 19054 4A6E S 1 INTEGER_32 1000  
C05522 Dynamisation - switch-off position 19053 4A6D S 1 INTEGER_32 1000  
C05523 Hysteresis window 19052 4A6C S 1 INTEGER_32 10000  
C05524 Track switch-over mode 19051 4A6B S 1 INTEGER_32 1  
