5 Function blocks
5.197 L_TbSampleHoldWord - sample & hold (for "WORD"data type)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.197 L_TbSampleHoldWord - sample & hold (for "WORD"data type)
This FB can save a signal from the "WORD" data type.
• The stored value is also available after mains disconnection.
Inputs
Outputs
Behaviour when switching the mains
The value loaded last is stored permanently when the supply voltage is switched off and reloaded
after the mains is switched on again.
• In order that the stored value is not immediately overwritten by the current input signal at wIn
after switching on the mains again, bLoad must be set to FALSE when the mains is switched on
again.
Function library: LenzeToolbox FB is available as of library V02.05.xx.xx!
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Required retain memory: 28 bytes
Identifier/data type Information/possible settings
wIn
WORD
Input signal
bLoad
BOOL
Saving of input signal
FALSE The value valid last at wIn is saved and output to wOut. A signal
change at wIn does not change wOut.
TRUE wIn is output at the output wOut.
Identifier/data type Value/meaning
wOut
WORD
Output signal
