Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C04271
Status
20304
4F50
S
1
INTEGER_32
1
C04272
Position unit
20303
4F4F
S
1
VISIBLE_STRING
1
C04273
Position value
20302
4F4E
S
1
INTEGER_32
10000
C04281
Status
20294
4F46
S
1
INTEGER_32
1
C04282
Speed unit
20293
4F45
S
1
VISIBLE_STRING
1
C04283
Speed value
20292
4F44
S
1
INTEGER_32
10000
C04350
Position unit
20225
4F01
A
2
VISIBLE_STRING
1
C04352
Speed input
20223
4EFF
S
1
INTEGER_32
10000
C04353
Starting position
20222
4EFE
S
1
INTEGER_32
10000
C04354
TP position
20221
4EFD
S
1
INTEGER_32
10000
C04357
Output position
20218
4EFA
S
1
INTEGER_32
10000
C04358
Speed output
20217
4EF9
S
1
INTEGER_32
10000
C04359
Status
20216
4EF8
S
1
INTEGER_32
1
C04325
Position unit
20250
4F1A
A
2
VISIBLE_STRING
1
C04326
Speed at the input
20249
4F19
A
2
INTEGER_32
10000
C04327
Starting position
20248
4F18
A
2
INTEGER_32
10000
C04329
Status
20246
4F16
S
1
INTEGER_32
1
C04445
Operation mode
20130
4EA2
S
1
UNSIGNED_32
1
C04446
Number of interpolation/extrapolati-
on steps
20129
4EA1
S
1
UNSIGNED_32
1
C04447
Change of direction of rotation during
extrapolation
20128
4EA0
S
1
UNSIGNED_8
1
C04430
Position unit
20145
4EB1
A
2
VISIBLE_STRING
1
C04431
Operation mode
20144
4EB0
S
1
UNSIGNED_32
1
C04432
Number of interpolation/extrapolati-
on steps
20143
4EAF
S
1
UNSIGNED_32
1
C04433
Change of direction of rotation during
extrapolation
20142
4EAE
S
1
UNSIGNED_8
1
C04434
Number of the interpolation cycles
20141
4EAD
S
1
UNSIGNED_32
1
C04435
Telegram failure detection
20140
4EAC
S
1
UNSIGNED_32
1
C04436
Position at the input
20139
4EAB
S
1
INTEGER_32
10000
C04437
Position at the output
20138
4EAA
S
1
INTEGER_32
10000
C04438
Speed at the output
20137
4EA9
S
1
INTEGER_32
10000
C04400
Number of the interpolation cycles
20175
4ECF
S
1
UNSIGNED_32
1
C04401
Position unit
20174
4ECE
A
2
VISIBLE_STRING
1
C04402
Position at the input
20173
4ECD
S
1
INTEGER_32
10000
C04403
Position at the output
20172
4ECC
S
1
INTEGER_32
10000
C04404
Speed at the output
20171
4ECB
S
1
INTEGER_32
10000
C04300
Speed at the output
20275
4F33
S
1
INTEGER_32
10000
C04301
Speed at the input
20274
4F32
S
1
INTEGER_32
10000
C04302
Speed limits
20273
4F31
A
2
INTEGER_32
10000
C04303
Limitation enabled
20272
4F30
S
1
UNSIGNED_8
1
C04304
Limitation active
20271
4F2F
S
1
UNSIGNED_8
1
C04305
Status
20270
4F2E
S
1
INTEGER_32
1
