3 Working with the FB editor
3.4 Creating/reconfiguring the interconnection
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
• Connections are only inserted when the dialog box is closed, which applies to all modules inser-
ted so far. They are displayed as lines or flags, like in the original, but re-routed.
• When the option Only accept connections between the added elements is selected, only tho-
se connections are added which are between the inserted elements. If this option is deselec-
ted, also those connections are added which are between the added elements and external
elements outside the selection if an element of the same type and instance name is available
in the target interconnection.
• When the Release assigned connections ... option is selected, connections are deleted in the
target interconnection to be able to add connections from the clipboard to inputs already as-
signed.
• The buttons serve to execute the following functions:

Tip!
It is not compulsory to add all elements to be inserted in one step. If required, you can first
add single elements and in further worksteps other elements of the list with another opti-
on for solving name conflicts.
Button Function
Insert Add elements selected in the list to the target interconnection
• Only possible if at least one element in the list has been selected for insertion.
• Insertion is also possible via the button if at least one element is selected
in the list for insertion.
• The original layout and the relative position of the inserted blocks to each other
are maintained.
• When copying across the devices, you also insert the corresponding separate
technical objects (port definition, variable declaration and user code declaration).
• The inserted elements are deleted from the list. If the list is empty, the dialog box
is closed and the connections are inserted depending on the selected option.
Close Close dialog box.
• You can also use or to close the dialog box if "Insert" is not active.
• The elements inserted into the target interconnection so far are maintained.
• The connections for the blocks inserted so far are inserted depending on the se-
lected option.
