5 Function blocks
5.167 L_TbDelay - delay
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.167 L_TbDelay - delay
This FB delays binary signals.
• The edge to be delayed is selected via the parameter C04010.
• The delay time is set via the parameter C04011.
• The function corresponds to the "DIGDEL" function of the 9300 servo inverter.
Inputs
Outputs
Parameter
Function library: LenzeToolbox
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
bin
BOOL
Input
Identifier/data type Value/meaning
bOut
BOOL
Output with time-delayed input signal
Parameter Possible settings Information
C04010 Selection of the edge to be delayed
0 Rising edge Lenze setting
1 Falling edge
2 Both edges
C04011 0.000 s 60.000 Delay time
• Initialisation: 0.001 s
E2XW E,Q
/B7E'HOD\
& W
W
&
