5 Function blocks
5.136 L_SdSetAxisData - machine parameters
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

Note!
The position values (e.g. setpoints, actual values, parameters, …) in the signal flow al-
ways use the set resolution, irrespective of the resolution the encoder supplies directly.
Resolution of the drive/motor
The machine parameters for the drive/motor are set via the drive interface
(SB LS_DriveInterface).
Multi-axis systems
When being connected via the electrical shaft, the drive is at least provided with two
measuring systems (master and slave).
• Each measuring system has an own resolution setting.
• The machine parameters (gearbox factors, feed constant, encoder resolution, and cy-
cle) for the master measuring system or master value must be identical for all drives
in the interconnection.
Technology applications "Electronic gearbox" and "Synchronism"
For both technology applications, the machine parameters of the master measuring sys-
tem are defined on the Application parameters tab in the "Master value scaling" dialog
level.
Electronic cam
For electronic cams, the machine parameters of the master measuring system are defi-
ned on the Measuring systems tab of the electrical shaft.
