Table of attributes
668
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C04399
Enable output x
20176
4ED0
A
8
UNSIGNED_8
1
C04318
Unit
20257
4F21
S
1
VISIBLE_STRING
1
C04310
Unit
20265
4F29
S
1
VISIBLE_STRING
1
C04314
Unit
20261
4F25
S
1
VISIBLE_STRING
1
C04085
Comparison operation
20490
500A
S
1
UNSIGNED_32
1
C04080
Comparison operation
20495
500F
S
1
UNSIGNED_32
1
C04081
Tolerance
20494
500E
S
1
INTEGER_32
100
C04082
Hysteresis
20493
500D
S
1
INTEGER_32
100
C04005
Function: |Counter| >= |Ref.|
20570
505A
S
1
UNSIGNED_32
1
C04100
Characteristic shape
20475
4FFB
S
1
UNSIGNED_32
1
C04101
x coordinates
20474
4FFA
A
9
INTEGER_32
100
C04102
y coordinates
20473
4FF9
A
9
INTEGER_32
100
C04045
Characteristic shape
20530
5032
E
1
UNSIGNED_32
1
C04046
x coordinates
20529
5031
A
127 INTEGER_32
100
C04047
y coordinates
20528
5030
A
127 INTEGER_32
100
C04065
Gain
20510
501E
S
1
INTEGER_32
10000
C04060
Dead band
20515
5023
S
1
INTEGER_32
100
C04061
Gain
20514
5022
S
1
INTEGER_32
10000
C04010
Select delayed edge
20565
5055
S
1
UNSIGNED_32
1
C04011
Delay time
20564
5054
S
1
UNSIGNED_32
1000
C04050
Filter time constant
20525
502D
S
1
INTEGER_32
1000
C04030
Gain
20545
5041
S
1
INTEGER_32
10000
C04070
Upper limitation
20505
5019
S
1
INTEGER_32
100
C04071
Lower limitation
20504
5018
S
1
INTEGER_32
100
C04110
Mean value - blocking zones
20465
4FF1
A
4
INTEGER_32
100
C04111
Width - blocking zones
20464
4FF0
A
4
INTEGER_32
100
C04035
Reference value
20540
503C
S
1
INTEGER_32
1
C04020
Time: Output = HIGH
20555
504B
S
1
UNSIGNED_32
1000
C04021
Time: Output = LOW
20554
504A
S
1
UNSIGNED_32
1000
Code
Name
Index
Data
Access
dec
hex
DS
DA
DT
Factor
R
W
CINH
