5 Function blocks
5.72 L_DevParWriteFix - write parameter
272
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Inputs
Identifier/data type Information/possible settings
bExecute
BOOL
Activates a write request.
FALSETRUE If the cycle time (dwCycleTime) = "0 ms" or the dwCycleTime input is
not assigned:
Write the parameter addressed via the inputs dwCode, dwSubcode,
dwComChannel and dwTargetAddress once with the value of the
data input which has been selected via dwDataTyp.
If cycle time (dwCycleTime) > "0 ms":
Write the parameter addressed via the inputs dwCode, dwSubcode,
dwComChannel and dwTargetAddress cyclically with the value of the
data input which has been selected via dwDataTyp.
TRUEFALSE Deactivate cyclic writing again.
dnData
DINT
Parameter value to be written
• The data input and thus the data type of the code to be written is selected via the
dwDataTyp input.
dwData
DWORD
nData
INT
wData
WORD
byData
BYTE
bData
BOOL
dwDataTyp
DWORD
Selection of the data input / declaration of the data type
0 dnData data input / DINT data type
1 dwData data input/ DWORD data type
2 nData data input / INT data type
3 wData data input / WORD data type
4 byData data input/ BYTE data type
5 bData data input/ BOOL data type
dwCode
DWORD
• If dwComChannel = "1" or bUseIndex = FALSE:
Code (0 ... 16000)
• If dwComChannel = "2" or "3" and bUseIndex = TRUE:
CANopen index (0x0 ... 0xFFFF)
dwSubcode
DWORD
Subcode (0 ... 255)
dwComChannel
DWORD
Interface
• Up to and including controller software version V07, only the selection "1" (own
device) is supported.
1 Own device
2 CAN on-board
3 CAN module
dwTargetAddress
DWORD
This input does not have any function.
dwTimeOut
DWORD
Time-out (0 ... 10000 [ms])
• Time in which the write request must have been processed.
• If the input is not assigned or if "0 s" is selected, time-out monitoring is deactiva-
ted.
