4 Short overview
4.11 FBs for winding technology
112
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.11 FBs for winding technology
L_PosGetTableSpeed Speed table
• Together with an FB instance
• ...of type L_PosPositionerTable this FB provides
five speed values from the VTSPEED variable ta-
ble.
• ...of type L_PosProfileTable this FB provides
speeds which are directly defined in the profi-
les.
LenzePositioning
V01.00.xx.xx
L_DevPositionerStateDecoder Status signals of the basic function "Positioning"
(SB LS_Positioner)
• From firmware 1.50, the
FB L_DevPositionerStateDecoder replaces the
FB L_PosDecoderStatePositioner .
LenzeDevice9400
V02.00.xx.xx
L_PosDecoderStatePositioner LenzePositioning
V01.00.xx.xx
L_PosSequencerStateDecoder Status signals of the sequence control
(FB L_PosSequencer )
• From firmware 1.50, the
FB L_PosSequencerStateDecoder replaces the
FB L_PosDecoderStateSequencer .
LenzePositioning
V02.00.xx.xx
L_PosDecoderStateSequencer LenzePositioning
V01.00.xx.xx
Function block Function From library
Function block Function From library
L_WndCalcDiameter Diameter calculation LenzeWinder V01.00.xx.xx
L_WndCalcLength Length calculation LenzeWinder V01.00.xx.xx
L_WndFrictionCompensation Friction compensation LenzeWinder V01.00.xx.xx
L_WndIdentMInertia Identification of the moment of inertia LenzeWinder V01.00.xx.xx
L_WndStopCtrl Stop controller LenzeWinder V01.00.xx.xx
L_WndTensionCurve Tensile force characteristic LenzeWinder V01.00.xx.xx
