5 Function blocks
5.100 L_LdVirtualMasterV - virtual master for electronic gearboxes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Parameter
Parameter Possible settings Information
C05100 VMaster: Operating mode
0 Continuous operation Lenze setting
1 Inching
2 Handwheel function
3 Selection of speed and mode via in-
put
Master speed 1 and the operating
mode are selected via the correspon-
ding inputs of the FB.
C05101
As of library V02.02.xx.xx
String of digits Speed unit
• Read only
C05102
As of library V02.02.xx.xx
-214748.3647 Unit/t 214748.3647 Reference speed
• Read only
• For input orientation for speed
entries.
C05103/1 -214000.0000 Unit/t 214000.0000 Master speed 1
• Initialisation: 1.0000 unit/t
C05103/2 -214000.0000 Unit/t 214000.0000 Master speed 2
• Initialisation: 1.0000 unit/t
C05104/1 0.0000 Unit/t 214000.0000 Positive inching: Speed
• Initialisation: 1.0000 unit/t
C05104/2 0.0000 Unit/t 214000.0000 Negative inching: Speed
• Initialisation: 1.0000 unit/t
C05105/1 0.010 s 130.000 Ramp: Inching
• Initialisation: 1.000 s
C05105/2 0.010 s 130.000 Ramp: Continuous operation/single
cycle
• Initialisation: 1.000 s
C05105/3 0.010 s 130.000 Ramp: Stop
• Initialisation: 1.000 s
C05114 -2147483647 2147483647 Status
• Display of the bit-coded output si-
gnal dnState.
C05117 -214748.3647 Unit 214748.3647 Speed at the output
• Read only
• Calculated from the speed signal
dnSpeedOut_s.
C05118 -214748.3647 Unit 214748.3647 External speed at the input
• Read only
• Calculated from the speed signal
dnExtMaster_s.
