Lenze E94A - Manual (Page 283)

Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
283
5 Function blocks
5.76 L_DevSMControlEncoder - control word for limiter
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
14 bSafelyLimitedPosition3 Safely limited position 3 (SLP3)
15 bSafelyLimitedPosition4 Safely limited position 4 (SLP4)
16 bSafeOperatingStop Safe operating stop (SOS)
23 bSafeStopEmergency Emergency stop (SSE)
29 bSpecialOperationActive Special operation is active
Identifier/data type Information/possible settings
dwControl
DWORD
Bit-coded control signal for the basic function "Limiter".
• Connect this output with the input LIM_dwControl of the SB LS_Limiter.
Bit* Identifier Requested/active safety functions with TRUE
* Relating to the output signal dwControl.
