5 Function blocks
5.140 L_SdSpeedSet - setpoint ramp generator
530
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.140.4 Setting and selection of the Ti times
16 different Tir, Tif and S-ramp times can be selected via parameters for the ramp generator.
• The selection is carried out binary coded via the selection inputs bTI1 ... bTI8:
5.140.5 Display of the machine-based variables
For a better assessment of the created setpoints/parameterised fixed values (% value) the machine-
based reference values are calculated and displayed:
The current setpoint is also calculated and displayed correspondingly.
Selected inputs Selection
bTI8 bTI4 bTI2 bTI1 Tir Tif S-ramp time
FALSE FALSE FALSE FALSE C04202 C04203 C04204
FALSE FALSE FALSE TRUE C04212/1 C04213/1 C04214/1
FALSE FALSE TRUE FALSE C04212/2 C04213/2 C04214/2
FALSE FALSE TRUE TRUE C04212/3 C04213/3 C04214/3
FALSE TRUE FALSE FALSE C04212/4 C04213/4 C04214/4
FALSE TRUE FALSE TRUE C04212/5 C04213/5 C04214/5
FALSE TRUE TRUE FALSE C04212/6 C04213/6 C04214/6
FALSE TRUE TRUE TRUE C04212/7 C04213/7 C04214/7
TRUE FALSE FALSE FALSE C04212/8 C04213/8 C04214/8
TRUE FALSE FALSE TRUE C04212/9 C04213/9 C04214/9
TRUE FALSE TRUE FALSE C04212/10 C04213/10 C04214/10
TRUE FALSE TRUE TRUE C04212/11 C04213/11 C04214/11
TRUE TRUE FALSE FALSE C04212/12 C04213/12 C04214/12
TRUE TRUE FALSE TRUE C04212/13 C04213/13 C04214/13
TRUE TRUE TRUE FALSE C04212/14 C04213/14 C04214/14
TRUE TRUE TRUE TRUE C04212/15 C04213/15 C04214/15
Parameter Information
C04225 Load reference speed
C04226 Setpoint speed - load
C04227 Machine reference speed
C04228 Machine setpoint speed
Parameter Information
C04221 Setpoint at the input
C04222 Target setpoint
C04223 Setpoint at the output
