5.41 L_DcGetBitOfWord - bit operation
This FB returns the state of a single bit within a "WORD" value.
Inputs
Outputs
Function library: LenzeDataConversion
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
wInput
WORD
Input signal
byBitNr
BYTE
No. (0 ... 15) of the bit of wInput the state of which is to be detected.
Identifier/data type Value/meaning
bBit
BOOL
State of bit byBitNr of wInput.
