5 Function blocks
5.44 L_DcNorm_aToNorm_n - signal converter
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.44 L_DcNorm_aToNorm_n - signal converter
This FB converts a scaled 16-bit signal into a scaled 32-bit signal.
Inputs
Outputs
Function
Function library: LenzeDataConversion
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
nIn_a
INT
Input signal
• 100 % ≡ 214 ≡ 16384
Note: If the input information has a value of "-32768", the value will internally be li-
mited to "-32767" and copied to the HighWord of the dnOut_n output.
Therefore, this FB cannot be used to combine the LowWord and the HighWord in or-
der to form a double word.
Identifier/data type Value/meaning
dnOut_n
DINT
Output signal
• 100 % ≡ 2 30 ≡ 1073741824
GQ2XWBQ Q,QBD
/B'F1RUPBD7R1RUPBQ
>@ %LW >@ %LW
Bit 0 Bit 31
Bit 0
dnOut_n
nIn_a
Bit 15
±
± 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
