5 Function blocks
5.113 L_PosProfileTable - profile data record management (simple)
422
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C04752/1...4
(Subcode 1 ... 4 ≡ profile no. 1 ... 4)
-214748.3647 Unit/t 214748.3647 Speed
C04753/1...4
(Subcode 1 ... 4 ≡ profile no. 1 ... 4)
0.0000 Unit/t 2 214748.3647 Acceleration
C04754/1...4
(Subcode 1 ... 4 ≡ profile no. 1 ... 4)
0.0000 Unit/t 2 214748.3647 Delay
C04755/1...4
(Subcode 1 ... 4 ≡ profile no. 1 ... 4)
0.000 s 2147483.647 S-ramp time
C04756/1...4
(Subcode 1 ... 4 ≡ profile no. 1 ... 4)
TP sequence profile
• Sequence profile for touch probe
residual path positioning.
0 No residual path positioning
1 Profile no. 1
... ...
4 Profile no. 4
C04757/1...4
(Subcode 1 ... 4 ≡ profile no. 1 ... 4)
Value is bit-coded: Touch probe configuration
• The touch probe channels to be
used are selected by setting the
corresponding bits to "1".
bits0 TP channel 1, rising edge Digital input 1
bits1 TP channel 1, falling edge
bit 2 TP channel 2, rising edge Digital input 2
bits3 TP channel 2, falling edge
bits4 TP channel 3, rising edge
Digital input 3
bits5 TP channel 3, falling edge
bits6 TP channel 4, rising edge
Digital input 4
bits7 TP channel 4, falling edge
bits8 TP channel 5, rising edge
Digital input 5
bits9 TP channel 5, falling edge
bits10 TP channel 6, rising edge Digital input 6
bits11 TP channel 6, falling edge
bits12 TP channel 7, rising edge
Digital input 7
bits13 TP channel 7, falling edge
bits14 TP channel 8, rising edge
Digital input 8
bits15 TP channel 8, falling edge
bit16 TP channel 9 Motor encoder zero pulse
bits18 TP channel 10 Load encoder zero pulse
bits20 TP channel 11 DFIN zero pulse
bits22 TP channel 12 DFOUT zero pulse
C04758 "Teach" position
• For execution via parameter chan-
nel.
01 The position assigned to the input
dnTeachPos_p is stored in the profile
selected via the input
dwTeachProfileNumber.
C04759/1 String of digits Position unit
• Read only
C04759/2 String of digits Speed unit
• Read only
C04759/3 String of digits Acceleration unit
• Read only
Parameter Possible settings Information
