Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C04192
Shift factor
20383
4F9F
S
1
INTEGER_32
1
C05900
Function block: ID
18675
48F3
S
1
UNSIGNED_16
1
C05901
Error number
18674
48F2
A
8
UNSIGNED_16
1
C05902
Response in case of error
18673
48F1
A
8
UNSIGNED_8
1
C05910
Code
18665
48E9
S
1
INTEGER_32
1
C05911
Subcode
18664
48E8
S
1
INTEGER_32
1
C05912
Hardware interface
18663
48E7
S
1
INTEGER_32
1
C05913
Target address
18662
48E6
S
1
INTEGER_32
1
C05914
Abort time
18661
48E5
S
1
INTEGER_32
1000
C05915
Cyclic reading time
18660
48E4
S
1
INTEGER_32
1000
C05920
Code
18655
48DF
S
1
INTEGER_32
1
C05921
Subcode
18654
48DE
S
1
INTEGER_32
1
C05922
Hardware interface
18653
48DD
S
1
INTEGER_32
1
C05923
Target address
18652
48DC
S
1
INTEGER_32
1
C05924
Abort time
18651
48DB
S
1
INTEGER_32
1000
C05925
Cyclic writing time
18650
48DA
S
1
INTEGER_32
1000
C05330
Unit
19245
4B2D
A
2
VISIBLE_STRING
1
C05331
Reference speed
19244
4B2C
S
1
INTEGER_32
10000
C05332
Mode
19243
4B2B
S
1
INTEGER_32
1
C05334
Clutch-in time
19241
4B29
A
3
INTEGER_32
1000
C05335
Input position
19240
4B28
A
3
INTEGER_32
10000
C05336
Basic speed
19239
4B27
S
1
INTEGER_32
10000
C05337
Output position
19238
4B26
S
1
INTEGER_32
10000
C05338
Output speed
19237
4B25
S
1
INTEGER_32
10000
C05339
Internal status
19236
4B24
S
1
INTEGER_32
1
C05270
Position unit
19305
4B69
A
2
VISIBLE_STRING
1
C05271
Encoder position evaluation
19304
4B68
S
1
INTEGER_32
1
C05272
Encoder mounting position
19303
4B67
S
1
INTEGER_32
1
C05273
Singleturn resolution
19302
4B66
S
1
INTEGER_32
1
C05274
Multiturn resolution
19301
4B65
S
1
INTEGER_32
1
C05275
Mode of position reconstruction
19300
4B64
S
1
INTEGER_32
1
C05277
Initialisation time of the encoder
19298
4B62
S
1
INTEGER_32
1000
C05280
Encoder input
19295
4B5F
S
1
INTEGER_32
1
C05281
Starting position
19294
4B5E
S
1
INTEGER_32
10000
C05282
Position output
19293
4B5D
S
1
INTEGER_32
10000
C05283
Speed output
19292
4B5C
S
1
INTEGER_32
10000
C05284
2nd encoder input
19291
4B5B
S
1
INTEGER_32
1
C05289
Status
19286
4B56
S
1
INTEGER_32
1
C05290
Position unit
19285
4B55
A
2
VISIBLE_STRING
1
C05291
Synchronised stretching/compression
19284
4B54
S
1
UNSIGNED_8
1
C05293
Additional speed
19282
4B52
S
1
INTEGER_32
10000
C05294
Speed input
19281
4B51
S
1
INTEGER_32
10000
C05295
Effective stretch factor
19280
4B50
S
1
INTEGER_32
10000
C05296
Starting position
19279
4B4F
S
1
INTEGER_32
10000
Code
Name
Index
Data
Access
dec
hex
DS
DA
DT
Factor
R
W
CINH
