5 Function blocks
5.2 L_CamContactor - cam group with switch-on and switch-off dynamisation
140
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C05525 Cam type
• Read only
0 Unknown cam type
1 Positive travel cams
2 Negative travel cams
3 Bidirectional travel cams
11 Positive time cams
12 Negative time cams
C05526 -214748.3647 Unit 214748.3647 Input position
• Display of the dnPosIn_p input si-
gnal in the real unit of the machi-
ne.
C05527 0 2147483647 Cam track
• Display of the track number
dnTrackNumber.
C05528
From library V01.01.xx.xx
0.0000 Unit 214748.3647 Cycle
• Display of the dnCycleLength_p
output signal in the real unit of
the machine.
C05529 Status messages: Status (bit coded)
• Bits that are not itemised are re-
served for future extensions.
• The bError error output will only
be set to TRUE if an error message
(bit 15 ... 31) is issued.
• Bit 31 is the default setting if one
or more other error bits (bit 15 ...
30) are set.
bits6 Reset of cam active
bits10 Zero crossing active
bits11 Cam switched on
Error messages:
Bit15 Limitation of dynamic cam sampling
bit16 Position is beyond the cycle
bits23 Invalid axis data structure
bits25 Invalid data track number
bits26 Invalid data track type
bits31 General error
Parameter Possible settings Information
