5 Function blocks
5.95 L_LdSetAxisVelocity - master value processing
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Parameter
Parameter Possible settings Information
C05034 -214748.3647 214748.3647 Status
• Display of the bit-coded output si-
gnal dnState.
C05035/1
As of library V02.02.xx.xx
String of digits Position unit
• Read only
C05035/2
As of library V02.02.xx.xx
String of digits Speed unit
• Read only
C05036 -214748.3647 Unit/t 214748.3647 Speed at the output
• Read only
• Calculated from the speed signal
dnSpeedOut_s.
C05037
As of library V02.02.xx.xx
-214748.3647 Unit/t 214748.3647 Speed at the input
• Read only
• Calculated from the speed signal
dnSpeedIn_s.
C05041 -214748.3647 Unit 214748.3647 Measured cycle
• Display of the output signal
dnTpTpDistance_p in the real unit
of the machine.
C05042 -214748.3647 Unit 214748.3647 Measured TP deviation
• Display of the output signal
dnDifference_p in the real unit of
the machine.
C05043 -214748.3647 Unit 214748.3647 Position at the output
• Display of the dnPosOut_p output
signal in the real unit of the ma-
chine.
C05048 TP: Deviation detected
• Display of the output signal
bTpDiffRecogn.
0 No deviation detected
1 Deviation detected
C05049 Cycle start
• Display of the output signal
bZeroPos.
0 No cycle start
1 Cycle start
