5.202 L_TbSubLim - subtraction with limitation
624
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.202 L_TbSubLim - subtraction with limitation
This FB carries out a subtraction with limitation.
• The value output to output dnOut is internally limited to ±2 31 -1.
• The bLimitActive output displays if a limitation is active.
Inputs
Outputs
Function library: LenzeToolbox
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
dnIn1
DINT
Minuend
dnIn2
DINT
Subtrahend
Identifier/data type Value/meaning
dnOut
DINT
Differential value (result of the subtraction)
• Internally limited to ±2 31 -1
bLimitActive
BOOL
Status signal "Limitation active"
TRUE The output signal is limited.
