Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
105
4 Short overview
4.4 Mathematical functions
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.4 Mathematical functions
4.5 Conversion of physical units
L_DcDWordToDInt Type converter
• DWORD  DINT
LenzeDataConversion
V01.00.xx.xx
L_DcDWordToWord Type converter
• DWORD  WORD
LenzeDataConversion
V01.00.xx.xx
L_DcDWordTo2Words Type converter
• DWORD  WORD (2 x)
LenzeDataConversion
V01.00.xx.xx
Function block Function From library
Function block Mathematical function From library
L_TbAbs Absolute value generation LenzeToolbox V01.00.xx.xx
L_TbAdd Addition without limitation LenzeToolbox V01.00.xx.xx
L_TbAddLim Addition with limitation LenzeToolbox V01.00.xx.xx
L_TbAddSubLim Addition and subtraction with limitation LenzeToolbox V02.04.xx.xx
L_TbDiv Division with remainder LenzeToolbox V01.00.xx.xx
L_TbDiv_n Division divisor selected as scaled signal [%] LenzeToolbox V01.00.xx.xx
L_TbIntegrate Integration with limitation LenzeToolbox V01.00.xx.xx
L_TbMul Multiplication without limitation LenzeToolbox V01.00.xx.xx
L_TbMul_n Multiplication with the multiplicand selected as sca-
led signal [%]
LenzeToolbox V01.00.xx.xx
L_TbMulDivLim Multiplication and division with limitation LenzeToolbox V02.02.xx.xx
L_TbMulLim Multiplication with limitation LenzeToolbox V01.00.xx.xx
L_TbNeg Sign inversion LenzeToolbox V01.00.xx.xx
L_TbNegSel Sign inversion (optional) LenzeToolbox V02.02.xx.xx
L_TbSub Subtraction without limitation LenzeToolbox V01.00.xx.xx
L_TbSubLim Subtraction with limitation LenzeToolbox V01.00.xx.xx
Function block Function From library
L_DcNorm_aToNorm_n Signal converter
• 16-bit signal (scaled)  32-bit signal (scaled)
LenzeDataConversion
V01.00.xx.xx
L_DcNorm_nToNorm_a Signal converter
• 32-bit signal (scaled)  16-bit signal (scaled)
LenzeDataConversion
V01.00.xx.xx
L_DcNorm_nToSpeed_s Signal converter
• 32-bit signal (scaled)  32-bit-speed signal
LenzeDataConversion
V01.00.xx.xx
L_DcSpeed_vToSpeed_s Signal converter
• 16-bit speed signal  32-bit speed signal
LenzeDataConversion
V01.00.xx.xx
L_DcSpeed_sToSpeed_v Signal converter
• 32-bit speed signal  16-bit speed signal
LenzeDataConversion
V01.00.xx.xx
L_DcSpeed_sToNorm_n Signal converter
• 32-bit speed signal  32-bit signal (scaled)
LenzeDataConversion
V01.00.xx.xx
L_SdDifferentiate Differentiation (position  speed) LenzeServoDrive
V01.00.xx.xx
L_SdIntegrate Integration (speed  position) LenzeServoDrive
V01.00.xx.xx
