5 Function blocks
5.113 L_PosProfileTable - profile data record management (simple)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C04760/1 -214748.3647 Unit 214748.3647 External target position
• Display of the dnExtPos_p input
signal in the real unit of the ma-
chine.
C04760/2 -214748.3647 Unit 214748.3647 Teach position
• Display of the dnTeachPos_p in-
put signal in the real unit of the
machine.
C04761/1 0 4 Selected profile
• Display of the dwProfileNumber
input signal.
C04761/2 0 4 Selected teach profile
• Display of the
dwTeachProfileNumber input sig-
nal.
C04763 DIS:bPosTeach
• Display of the bPosTeach input si-
gnal.
0 FALSE
1 TRUE
C04764 DIS:bBusy
• Display of the output signal
bBusy.
0 Profile parameters are ready.
1 Conversion is active, no access pos-
sible to the profile parameters at the
moment.
C04765 -2147483647 2147483647 Status
• Display of the bit-coded output si-
gnal dnState.
C04767/1...4
(Subcode 1 ... 4 ≡ profile no. 1 ... 4)
From library V02.05.xx.xx
S-ramp mode
• Will be supported as of controller
software version V5.0.
With software versions < V5.0,
this parameter has no function.
0 Second S-ramp time is not active.
• The S-ramp time parameterised
in C04755/1...4 is used for the ac-
celeration and deceleration pha-
se.
1 Second S-ramp time is active for de-
celeration.
• The S-ramp time parameterised
in C04755/1...4 is only used for
the acceleration phase.
• For the deceleration phase, ho-
wever, the second S-ramp time
parameterised in C04768/1...4 is
used.
C04768/1...4
(Subcode 1 ... 4 ≡ profile no. 1 ... 4)
From library V02.05.xx.xx
0.000 s 2147483.647 Second S-ramp time
• Will be supported as of controller
software version V5.0.
With software versions < V5.0,
this parameter has no function.
• The second S-ramp time is only
used for S-ramp mode "1" for the
deceleration phase.
Parameter Possible settings Information
