L_LdSyncOperation - master value connection

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

Outputs

Identifier/data type

Value/meaning

dnState

DINT

Status (bit coded)

bits10 Zero crossing active (corresponds to the bXZeroPos output signal)
bits14 Internal limitation for calculation:

The dnYSpeedOut_s and/or dnYSpeedOut_s speed outputs are not

able to follow the change in the resulting dnActXPos_p master posi-

tion. The reference to the master cycle gets lost.

Bit15 Group error (see bit 16 ... 31)
bit16 The master position at the dnXPosIn_p input is outside of the permis-

sible modulo value range of the master measuring system (see

XAxisData input).

bits18 The master measuring system and/or the slave measuring system

(the XAxisData and YAxisData inputs) are not modulo measuring sys-

tems, or the modulo cycle in one of the measuring systems is zero.

bits21 Incorrect input value:

• Error when selecting the offset position: The dnXOffset_p input

exceeds the permissible DINT value range minus the master cycle.

(DINT value range = ±2

31

-1 [increments] ≡ ±32768 [rev])

• Gearbox denominator = "0"

bits23 Error in the measuring system:

• The pointers at the XAxisData and/or YAxisData inputs do not re-

fer to a valid axis data structure.

• If coupling is performed via cycles (C05090 = 1), modulo measu-

ring systems must be specified at the XAxisData and/or

YAxisData inputs.

dnYSpeedOut_s

DINT

Output of the setpoint speed (y speed) as a speed signal

• Scaling: 2

26

≡ 15000 [rpm]

• The signal can be used for direct coupling to the LS_PositionFollower system

block (the PF_dnSpeedAdd1_s input).

• Shifts in the resulting master position (e.g. when switching-off the FB via bEnable

= TRUEFALSE) will not be displayed via this signal. The position reference to the

dnXActPos_p master cycle may get lost!

• If the FB is deactivated (bEnable = FALSE), a value of "0" is output.

• Using the measuring system data at the YAxisData input, the setpoint speed is in-

dicated in the real unit of the machine in C05097.

dnXSpeedOut_s

DINT

Output of the resulting master speed as a speed signal

(The resulting change in the dnXPosIn_p master position and the dnXOffset_p mas-

ter value adjustment is displayed.)

• Scaling: 2

26

≡ 15000 [rpm]

• This signal can be used for the coupling of further slave drives.

• Angular trimming via the dnXOffset_p input will be accounted for in this signal.

• The signal directly results from the differentiation of the resulting dnXActPos_p

master position. Considerable position step changes at dnXActPos_p lead to a li-

mitation of this output. In this case, the signal does not display the position step

change at dnXActPos_p.

• If the FB is deactivated (bEnable = FALSE), the resulting master speed is output as

before.

• Using the measuring system data at the XAxisData input, the resulting master

speed is displayed in the real unit of the master measuring system in C05096.

dnXActPos_p

DINT

Output of the resulting master position in [increments]

• If bEnable = TRUE, the dnXPosIn_p master position offset against the dnXOffset_p

offset value will be output. The output signal is limited to the modulo value range

of the master measuring system (XAxisData).

• If the FB is deactivated (bEnable = FALSE), the resulting master position is output

as before.

• Using the measuring system data at the XAxisData input, the resulting master

position is displayed in the real unit of the master measuring system in C05098.
