4 Short overview
4.13 FB reference list - 9300 Servo PLC
130
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
L_TBResetBitOfWord* Resets a bit of a WORD value
to "0".
LenzePLCToolBox L_DcResetBitOfWord Resets a bit of a WORD value
to "0".
L_TBSetBitOfByte* Sets a bit of a BYTE value to
"1".
LenzePLCToolBox L_DcSetBitOfByte Sets a bit of a BYTE value to
"1".
L_TBSetBitOfDword* Sets a bit of a DWORD value
to "1".
LenzePLCToolBox L_DcSetBitOfDWord Sets a bit of a DWORD value
to "1".
L_TBSetBitOfWord* Sets a bit of a WORD value
to "1".
LenzePLCToolBox L_DcSetBitOfWord Sets a bit of a WORD value
to "1".
L_TBSquareWave Rectangular pulse generator
with variable pulse/dead ti-
me.
LenzePLCToolBox L_TbOscillator Rectangular pulse generator
with parameterisable pul-
se/dead time.
L_TpConfigDigInX Configures a touch probe in-
put (function)
LenzeTpDrv - -
L_TpGetLastScanDigIn1...4 Provides touch-probe sig-
nals
LenzeTpDrv L_SdTouchProbe Touch probe processing
L_TRANS Edge evaluation LenzeDrive.lib L_TbTransition Signal edge evaluation
L_WndAccTorque Acceleration compensation LenzeWinder - -
L_WndCalcDiameter Diameter calculation LenzeWinder L_WndCalcDiameter Diameter calculation
L_WndCalcLength Length calculation LenzeWinder L_WndCalcLength Length calculation
L_WndCalcThickness Thickness calculation LenzeWinder - -
L_WndConvActPos Actual dancer value condi-
tioning
LenzeWinder - -
L_WndConvMSet Torque setpoint converter LenzeWinder - -
L_WndConvNSet Speed setpoint converter LenzeWinder - -
L_WndFrictionCurve Friction compensation LenzeWinder L_Wnd
FrictionCompensation
Friction compensation
L_WndGearRatio Gearbox factor changeover LenzeWinder - -
L_WndIdentFriction Identification of the friction
characteristic
LenzeWinder L_Wnd
FrictionCompensation
Friction compensation
L_WndIdentMInertia Identification of the mo-
ment of inertia
LenzeWinder L_WndIdentMInertia Identification of the mo-
ment of inertia
L_WndMInertia Mass inertia calculation LenzeWinder - -
L_WndProcessCtrl Dancer / tension control LenzeWinder - -
L_WndStopCtrl Stop controller LenzeWinder L_WndStopCtrl Stop controller
L_WndTensionCurve Tensile force characteristic LenzeWinder L_WndTensionCurve Tensile force characteristic
Function block for 9300 servo PLC Function block for 9400 Servo Drives
Name Description Function library Name Description
* Function (no function block)
