5.113.3

Positioning modes

Depending on the traversing range/application, you can select between different positioning mo-

des which are described in the below table.

Note!

For absolute positioning, the home position must be known!

• If an absolute positioning process (positioning modes 1 ... 2 and 11 ... 16) is started alt-

hough the home position is not known, an error message occurs.

• In this case a programming error has occurred and the program flow must be reset.
• If the error only occurs in a sequence profile, the last valid deceleration is used to

decelerate the drive to standstill.

The modulo positioning modes may involve reversing processes!

• If a modulo positioning process (positioning modes 11 ... 16) is started at an initial

speed other than zero, the target position may be overtravelled and a reversing pro-

cess may follow, depending on the selected deceleration / S-ramp time parameters.

This would also cause e.g. counter-clockwise rotation in the "Absolute CW (modulo)"

positioning mode.

Positioning mode

Supported traversing range

Unlimited

Limited

Modulo

1 Absolute

The axis travels to an absolute position.

• Reference for the absolute position is zero position.

• The home position must be known.

• The traversing range is limited:

• to 214748.3647 [unit]

• by the internal display area (±2

31

increments)

2 Absolute TP

Like mode 1, but with profile change on touch probe detection.

Touch probe positioning

.

( 428)

5 Relative

The axis is traversed by a distance.

• Reference for the distance is the target position of the profile execut-

ed before.

• The feed per positioning is limited:

• to 214748.3647 [unit]

• by the internal display area (±2

31

increments)

6 Relative TP

Like mode 5, but with profile change on touch probe detection.

Touch probe positioning

.

( 428)

7 Speed

Continuous constant travel.

• This mode does not approach a defined position, but follows the pro-

file.

• Acceleration and deceleration are based on profile values.

• The traversing direction is defined by the sign of the traversing speed.

• Stopped through break signal.

8 Speed TP

Like mode 7, but with profile change on touch probe detection.

Touch probe positioning

.

( 428)
