5 Function blocks
5.140 L_SdSpeedSet - setpoint ramp generator
528
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.140.1 Setpoint path
• The signals in the setpoint path are limited to ±200.00 % of the motor Motor reference speed
(C00011).
• The signal at dnSpeedSetpointIn_n is first led via the function "Selection of fixed setpoints".
• A selected fixed setpoint switches the input dnSpeedSetpointIn_n inactive and the subsequent
signal conditioning uses the selected fixed setpoint.
• By setting the input bInvertSetpoint to TRUE the input signal of the ramp generator can be in-
verted.
5.140.2 Fixed setpoints
In addition to the direct setpoint selection via the input dnSpeedSetpointIn_n fixed setpoints can be
preset in C04200/1...15.
• These fixed setpoints can be called binary coded any time via the selection inputs bJog1 ... bJog8,
so 15 options are available.
• The number of selected inputs to be assigned depends on the number of required fixed set-
points.
Selected inputs Used
Setpoint
bJog8 bJog4 bJog2 bJog1
FALSE FALSE FALSE FALSE dnSpeedSetpointIn_n
FALSE FALSE FALSE TRUE C04200/1
FALSE FALSE TRUE FALSE C04200/2
FALSE FALSE TRUE TRUE C04200/3
FALSE TRUE FALSE FALSE C04200/4
FALSE TRUE FALSE TRUE C04200/5
FALSE TRUE TRUE FALSE C04200/6
FALSE TRUE TRUE TRUE C04200/7
TRUE FALSE FALSE FALSE C04200/8
TRUE FALSE FALSE TRUE C04200/9
TRUE FALSE TRUE FALSE C04200/10
TRUE FALSE TRUE TRUE C04200/11
TRUE TRUE FALSE FALSE C04200/12
TRUE TRUE FALSE TRUE C04200/13
TRUE TRUE TRUE FALSE C04200/14
TRUE TRUE TRUE TRUE C04200/15
Number of the fixed setpoints required Number of the selection inputs to be assigned (bJog1 ... bJog8)
1 at least 1
1 ... 3 at least 2
4 ... 7 at least 3
8 ... 15 4
