Function blocks

5.75

L_DevSMControlDecoder - control signals from the safety module

280

Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

5.75

L_DevSMControlDecoder - control signals from the safety module

The SM3xx safety module uses the bit-coded control signal SM_dwControl of the

SB LS_SafetyModuleInterface to transmit information about requested or active safety functions to

the application. The FB decodes the control signal into individual boolean control signals for further

use in the FB interconnection.

• The corresponding actions (e.g. braking, braking to standstill, holding of the standstill position)

must be executed by the application, e.g. via the basic function "Limiter".

• Several safety functions can be requested/be active at the same time.
• The safety functions that are supported depend on the safety module used.
• The FB functionality corresponds to a "DWORDBOOL" converter, but the boolean outputs of

the FB are called according to their meaning.

Inputs

Outputs

Function library:

LenzeDevice9400

FB is available as of library V02.00.xx.xx!

FB may only be used for firmware as of V1.50!

Runtime software licence:



Motion Control HighLevel



Motion Control TopLevel

Identifier/data type

Information/possible settings

dwControl

DWORD

Input for the bit-coded control signal from the safety module.

• Connect this input with the output SM_dwControl of the

SB LS_SafetyModuleInterface.

Bit*

Identifier

Requested/active safety functions with TRUE

1 bSafeStop1

Safe stop 1 (SS1)

2 bSafeStop2

Safe stop 2 (SS2)

* Relating to the input signal dwControl.

/B'HY60&RQWURO'HFRGHU

E6DIH6WRS

E6DIHO\/LPLWHG6SHHG

E6DIH'LUHFWLRQ3RV

E6DIH'LUHFWLRQ1HJ

E(QDEOH6ZLWFK

E6DIHO\/LPLWHG,QFUHPHQWV

E2SHUDWLRQ0RGH6HOHFWRU

E6DIHO\/LPLWHG3RVLWLRQ

60[[FRQWUROZRUG

GZ&RQWURO

E6DIH2SHUDWLQJ6WRS

E6DIH6WRS(PHUJHQF\

E6SHFLDO2SHUDWLRQ$FWLYH
