5.7 L_CamSetContDataPDO - contactor data selection via inputs/PDOs
170
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C05565/1...8 -214748.3647 Unit 214748.3647 Cam switch-off position 1 ... 8
• Only with travel cams
• Display of the input signal
dnCamOff1...8 in the real unit of
the machine.
C05566/1...8 0.000 s 134217.728 Cam break time 1 ... 8
• Only with time cams
• Display of the input signal
dnCamOff1...8.
C05567/1...8 Cam status 1 ... 8
• Read only
0 Undefined cam
1 Cam is not active
2 Cam is active
C05569 Status messages: Status (bit coded)
• Bits that are not itemised are re-
served for future extensions.
• The bError error output will only
be set to TRUE if an error message
(bit 16 ... 31) is issued.
• Bit 31 is the default setting if one
or more other error bits (bit 16 ...
30) are set.
bits7 Invalid cam number
Error messages:
bits23 Invalid axis data structure
bits27 Invalid cam type
bits28 Invalid contactor data
(wrong parameterisation)
bits31 General error
Parameter Possible settings Information
